Roland MPU-103





roland mpu 103

  audio demo trend price : 50-100€
manual demo comments

Roland MPU-103 (1985)
Midi Channel Filter Converter



Device filters or converts data from a Midi channel stream.

midi channel filter

filer number

not INFORMATION (weight: 1 Kg)
main panel features 2rotative selector, 2 push buttons switches and 2 leds diode.

Back panel terminal connectors:
- MIDI IN
- MIDI OUT
- MIDI THRU

Power Supply is a standard 9V DC polarity -)




not TECH Midi filter and converter based on MC6801 family.
The MPU can be handy for early synthesuzer with basic implementation like little buffer memory or only a OMNI MIDI IN implementation like the Roland Jupiter 6, a problem if you use same THRU port for various machines chain.
Another example is the Elka Synthex that may crash if it receives some datas like Clock or SMPTE, in that case the MPU just filters all that stuff except note ON/OFF using the appropirate KEY EVENT ONLY function.


original boxed





not FUNCTIONS MPU 103 can help in 2 different cases:
1- It filters all data and let pass only note ON/OFF
2- It changes a data from a channel to another

original boxed


Mpu 103 minirack midi filter





manual
MPU 103 USER MANUAL






mpu103 service manual
MPU-103 service manual





manual


- handy for early Midi devices

manual

-a whole box for such an elementary function

comment


REVIEW "Can be useful is you have a daisy chain or few midi outputs"
