SOUND machine generates 4 analog percussions:
BD : kick
SD : snare
RS : rimshot
HH: hi-hat.
![kick drum](diagram.jpg)
SOUND EDIT is limited to 2 basic functions:
-
TONE color is a simple filter for brilliance control
- ACCENT emphasizes all sounds present in a step.
![tone](tone-a.jpg)
SEQUENCER only STEP entry mode: It is quite easy to write a pattern but without display you have to figure out and count the beats to make something not too randomish. Note that Hi-hats are NOT programmable as they just could be set playing at 8ths/ 12ths / 16ths or OFF.
SYNC system works only as master clock-
2 kinds of trigger pulses to sync other machines like synth arpeggiators:
1- DBS outputs a pulse for each step
2- CSQ outputs a pulse at each ACCENT step and If a 1.5mm jack is connected to CSQ, it does not affect instruments dynamic.
![start](seq1.jpg)
PROGRAMMING to edit a pattern follow this procedure (described also under the drum machine) :
1- Select PATTERN WRITE then get one of the 8 available slots (6 with 16 steps at 4/4 signature or 2 at 12 steps for 3/4) from Bank A- B, choose one of the sound and press START to write a beat or STOP for a step rest.
2- Back to PATTERN PLAY and START (or use pedal switch). The VARIATION function alternates patterns A- B automatically or manually selecting the relative bank.
![edit](step-rec.jpg)
MEMORY the patterns memory is retained as long as there are batteries. No possible memory patterns backup.
![start](boss-dr-55-pic.jpg)
MODDING even if there is not much space left into the box, it seems there are many custom modifications like Kick DECAY / TUNES - that would make it more usable and desirable.
Check out an modification vid below:
![modded dr55](modded-dr55.jpg)
VST PLUGIN / SAMPLED VERSION there are some free and commercial samples set:
|
name |
price |
link |
demo |
![Waveshapper](set1.jpg) |
waveshaper |
DR-55 SAMPLE PACK:
free light version
commecial version |
![effet](../../../../../icon/link.gif) |
![demo](../../../../../icon2/demo.gif) |
![VST](set2.jpg) |
Doctor 55 |
commercial
VST- samples |
![effet](../../../../../icon/link.gif) |
![demo](../../../../../icon2/demo.gif) |
![dr55 free samples](set3.jpg) |
Dubsound |
free
sample pack |
![effet](../../../../../icon/link.gif) |
N/A |
AUDIO DEMO
If you want to share you dr 55 demos, just UPLOAD them :)
Soundcloud DR-55
VIDEO CLIP SELECTION
|
