Akai XR-20
Beat Production Station (2008)
Beat Production Station (2008)
Company: Akai
Model: XR20
Keyboard : 12 Touch Sensitive Pads (8 levels + 3 curves)
Display Type: LCD
Dimensions: 34 x 32 x 13 cm
Weight: 1,7 kg
dates: 2008
Synthesis: digital PCM
N.samples: 720 PCM
Resolution: 16/24 bits
Polyphony: 32 voices
Filters: digital low pass (no resonance)
Memory none
MIDI: yes
Envelope: attack and release for synth section , decay segment for all
Sync: Midi clock slave / master
CV gate: no
Memory: 100 rom patterns + 100 blank -Notes: 150,000 Patterns: 200 (100 user, 100 preset) Songs: 100, 100 ram kit + 100 rom kits.
12 Touch Sensitive Pads assignable to Midi nottes. Backlit pads that follow the beat - blue like neon display lcd with adjustable intensity - tacky or flashy?
Rear panel connectors:
- Headphone output
- 2x 6.3mm mono jack outputs (L/R) + 1 x 6.3 mm stereo jack AUX out volume can be set by rear knob
- 2x Footswitch connectors (1 x start/stop, 1x TAP/A/B/Fill)
- Midi interface (out can be thru)
PSU: external or batteries (6 X AA 1,5V ) or with power supply 12VDC half ampère
Nothing... yet!
we have a FREE collection of XR20 sounds! sampled with mighty lofi Akai MPC60 (read) - visit our sample shop!
- Owner's manual download
- No service manual, maybe in a couple of years!
Scegli tra la vasta selezione di blocchi già pronti più recenti: intro a tutto schermo, caroselli immagini di bootstrap, Slider dei contenuti, galleria di immagini responsive con lightbox, parallax-scrolling, sfondi video, menu hamburger, intestazioni fisse e altro ancora.
Basically the XR20 is a digital programmable drum machine with a 32 voices sound generator based on 700 PCM (16 or 24 bits) samples.
The second main part is the internal sequencer that can be programmed by the 12 sensible pads or external midi keyboard.
- 9 levels of quantisize from 1/4 to 384th notes.
-3 swing levels (0,54, 58,52%)
Internal frequency from 30 to 300 BPM (can be set also by TAP button)
-Possible tempo change and special odd time signature.
Some classic functions: lenght set, time offset, assign a name, erase instrument/part, copy track, append data, transpose. Patterns are chained to SONG.
- Step by step mode or real time with pad-entry or external Midi data.
- 96 ppq resolution.
414 drums percussion including standard acustic drums but also drum machines including classic 909, 808, beat, analog, digial and much more. Some are really good. Some sounds like old 90 records.
More particular percussions, classic scratches and strange FX like sirens and some useless samples.
It includes some synth shots, also rhodes, dirty piano, brass. These can be played on 3 octaves (not multisampled).
FREE XR20 SAMPLE PACK
-Notes: 150,000
-Patterns: 200 (100 user, 100 preset)
-Songs: 100
- cheap built
- some samples
- all in one controller
-good price
