Soundtracker ST-01 original synthesizer source





commodore amiga500

infoCountry: USA
Weight (amiga 500) : 3,1 Kg
Dimensions (amiga 500): 325 x 470 x 65 mm
audio demo trend price : free
manual video comments

The Soundtracker
How does the St-01 amiga samples originally sound?


The trackers are typical affordable (or free) musical sequencers used by various system.

The concept was born in 1987 with the ULTIMATE SOUNDTRACKER (EAS Computer Technik) written by Karsten Obarski for the computer . Commodore Amiga uses the 4 PCM samples voices generated by PAULA audio chip.

logo







music tracker


editWhat's a MUSIC TRACKER?
The original tracker was based on simple sequencers using internal samples (not Midi samplers).
Each samples was entered as a note (pitch samples) into different channels lined up on columns patterns.


paula

-LEFT - AMIGA TRACKER - The samples can be usually edited (eg.volume and EG for early trackers) depending on the software, then the song can be saved on various "module" format like .mod, IT, S3M [...]

edit famous Module Echoing HEAR





editMUSIC TRACKER Influence
Right after the Ultimate Sountracker release, many freeware / shareware clones appeared and music trackers began to be appreciated amongst DEMO SCENE people, not to mention some commercial blockbuster games.

zx spectrum trACKER
left: spectrum tracker, on the right modern Renoise

The tracker concept is born with the Amiga then evolved and spread to both modern platforms (e.g PC RENOISE) and even to older computers (C64, spectrum, MSX, Atari St). Today tracker softwares handle much more tracks, feature high quality samples, filtering, VST effects, virtual instruments.





editThe tracker sound collection ST-XX
In order to reduce file dimension and simplify songs swaps, many modules did not include the most common samples since these were on available on a standard free sound library collections called "ST-" followed by a number indicating the disk number (officially from ST-01 to ST-116).

Originally most of these ST-XX samples were recorded from synthesizers or drum machines from this era, but seldom reported the original recorded source (copyright?) but some short "hints" (e.g.D50 heaven-> staccato heaven).
test


edit ST-01 DISK
The first disk ST-01 was probably the most popular and used as it contains some very classic sound you heard hundreds of time on classic Amiga songs. According to some web indications, name's linkenes, I managed to record some original synth sound sources - not an easy task since Amga ST-01 short samples were sampled at 8/11 kHz at low 8 bits resolutions with many audio artefacts.

Most of the st-01 samples were recorded from 3 common synthesizers:
- Roland D-50
- Yamaha Dx21 / 27 / 100
- Casio Cz101 / 1000



music tracker
Following a full 44 kHz 24 bits STEREO recording from original machines, this will be updated when new sounds (for suggestions drop me a edit LINE).




edit
ST-01 SAMPLES FROM ROLAND D50
A classic digital synthesizer from 1987 based on LA synthesis, also well-known to retrogamers for the Roland MT32 module.


roland d50



ST name Synth preset ST01 sample original D50 sample remarks
Call Living Calliope demo demo
Heaven Staccato Heaven demo demo
JahrMarkt2 Metal Harp demo demo
Jetes Jete Strings demo demo
TineWave Tine Wave demo demo
Pizza Pizzagogo demo demo
NightMare NightMare demo demo
Mechanic1 Intruder FX demo demo

edit These short mp3 samples are provided as tutorial for educational purposes, Roland D50 samples are still copyrighted and we cannot provide any full samples set. We do respect copyright.




edit ST-01 SAMPLES FROM YAMAHA DX-TX 4OP line
Many samples come also from 4 OP FM synthesizers developed by Yamaha.
The 4 OP FM machines were basically buget version of more DX7 traditional 6 OP (6 sinewave oscilaltors) with simpler sound and less algorithms. The 4 operators family are based on similar IC YM chip / DAC compatible between them, consequently it is actually totally impossible to tell the specific the true original module or synthesizer recorderd on the Amiga samples.

4 op synth edit According to the ST-01 likeness names, it is mostly probable that the sound sets comes from DX21 presets.


Most common 4 OP FM machines are:
- 4OP with standard sinewave: DX21 - DX27 - DX100
- 4OP with sinewave + harmonic variations: TX81Z - DX11.
Later 4 OP models c.a 1988 (V50- TQ5 - WT11 - YS100/200) could not be featured into the ULTIMATE SOUNDTRACKER since it has been released in 1987.


ST name Synth preset ST01 sample DX sample remarks
Heifer Heifer bell demo demo
FunkBass Elec Bass demo demo
SixTease <6 Tease> demo demo
MetalKeys MetalKeys demo demo
HeavySynth HeavySynth demo demo
Horns Horns demo demo
Koto Kotokoto demo demo
DigDug Solid Bass demo demo also known as more famous "lately bass"

edit HINT: FM synthesis has been also implemented on famous PC soundcards ADLIB/SOUNDBLASTER with the OPL chip.





edit ST-01 SAMPLES FROM CASIO CZ line - SOON! in the mean time you can read about PD synthesis on the CASIO CZ101 page

casio cz101

ST name Synth preset ST01 sample original CZ sample remarks
soon











video VIDEO SELECTION

video1 video2 renoise
Axel F Spectrum tracker renoise tracker












Company: EAS
Tile: Ultimate Soundtracker
Class: Retro software
License: Commercial
Platform: Commodore Amiga
Author: Karsten Obarski
Dates: 1987
Synthesis: PCM
Format: IFF
Sample Resolution: 8 bits
Polyphony: 4 voices
SYNC: none
Envelope: EG amp
CPU: Motorola 68XXX
RAM: 512kb
OS: latest V2.6





brochure



brochure



brochure
