OVERVIEW Budget rackmount digital effect with no display, no midi and missing saving option.
The Microverber 3 offers 16 bit linear PCM and 256 programs: 144 reverb programs + 96 delay programs + 16 special effects programs as well as High and Low Frequency Equalization. Pretty intuitive with three potentiometers on the left set the input level the processed / unprocessed signal balance (mix), and the output level. On the right, two rotary switches with sixteen positions allow you to select the algorithm and its variation. In the center, a two-band equalizer corrects the processed signal.
ALGORITHMS There are nine reverberation algorithms: rooms (small, medium, large), halls (medium, large), plates, chambers, gates, and reverse. The other seven include five delays (short, medium, long, medium with feedback, long with feedback), a multitap, plus a special effects category (FX). Sixteen variations are available for each of these sixteen algorithms. In terms of reverbs, they act over time, the acoustics of the simulated space and attack.
Bandwidth (effect) : 20 - 15000 Hz
Bandwidth (direct) : 20 - 20,000 Hz
Dynamic : 85 dB
Harmonic distortion : 0.15%
Sampling frequency : 31.25 kHz
Quantization : 16 bits
Processing speed : 2 Mips
Processing memory : 32 K
Inputs : 1/4 jacks (x2)
Outputs : 1/4 jacks (x2)
Power supply : separate
Size : 19 inch 1U rack
ROM memory : 256
POWER REQUIREMENTS9 Volts AC, 5 Volt Amps external Transformer
DIMENSIONS (W x H x D)19”x1.75”x4”
WEIGHT2 lbs. 10 oz. 1kg
